Data Logger Accessories

Order number M83200 Availability Usually in stock Accessories Wind Vane Thies First Class POT heatable Documents Module AC-Converter 5V_M83200 Download PDF Description The module M83200 converts AC signal inputs into pulse outputs and provides configurable 5 V outputs. The module M83200 contains: 4 independent AC signal converters To adapt low amplitude AC (e.g. sinusoidal) signals [...]

Order number M83575 Availability Usually in stock Documents Module_M83570+M84100_M83575_temp.pdf Download PDF   Description Ammonit’s M83575 includes two modules designed to establish stable data transmission on two wire RS485 connections between Meteo-40 data logger and various sensors: M83570 Biasing module for RS485 (half-duplex, purpose: set biasing voltage on data lines according to RS485 specification) M84100 Isolating [...]

Order number M83570 Availability Usually in stock Documents Module 10ports RS485-5V_M83570 Download PDF Description M83570 provides: Biasing resistor circuit to set voltage for RS485 (configurable with jumpers) RS485 bus termination (120Ω / configurable with jumpers) 10 individually configurable ports with various configuration possibilities Stabilized 5V / 110mA output Specifications Electrical characteristics (Default settings) Parameter Pin [...]

Order number M27804 / M27806 Availability Usually in stock Download PDF Description M27804 GFR Plastic Cabinet TMR M27806 GFR Plastic Cabinet OVP Robust GFR cabinets for Meteo-40 data loggers CE-certified robust and weatherproof glass fibre reinforced plastic casing Easy to install and maintain Protection against weather and condensation damage, vandalism, theft Accommodation of optional components [...]

Order number M41410 Availability Usually in stock Download PDF Description Robust steel cabinets for Meteo-40 plus data loggers CE-certified robust and weatherproof steel casing Easy to install and maintain Protection against weather and condensation damage, vandalism, theft Accommodation of optional components Specifications Characteristic Application Special projects with numerous measurement devices Dimensions [mm] 900 x 700 [...]

Order number M27105 / M27100 / M27107 / M37100 / M37105 / M37200 Availability Usually in stock Download PDF Description Detailed Order-No. M27105    Steel cabinet C7.7 with terminals “TMR” for METEO‐40M M27100    Steel cabinet C7.7 with terminals “POT” for METEO‐40M M27107    Steel cabinet C7.7 prepared for OVP for METEO‐40M M37100    Steel cabinet C7.7 with terminals [...]

Order number M16100 / M16200 / M26150 / M26100 / M26200 / M36150 / M36100 / M36200 Availability Usually in stock Download PDF Description Detailed Order-No. M16100 Steel cabinet C6 with terminals for METEO-40S M16200 Steel cabinet C6 for METEO-40S prepared for OVP M26150 Steel cabinet C6 with terminals “TMR” for METEO-40M M26100 Steel cabinet [...]

Order number M41200 Availability Usually in stock Download PDF Description Robust steel cabinets for Meteo-40 plus data loggers CE-certified robust and weatherproof steel casing Easy to install and maintain Protection against weather and condensation damage, vandalism, theft Accommodation of optional components Specifications Characteristic Application Obstacle lights, power supply solutions Dimensions [mm] 550 x 500 x [...]

Order number M51101 Availability Usually in stock Documents Power Supply Solar Module 100W-12V_M51101 Download PDF

Order number M51052 Availability Usually in stock Documents Power Supply Solar Module 50W-12V_M51052 Download PDF
