Order number
M83200
Availability
Usually in stock
Accessories
Documents
Description
The module M83200 converts AC signal inputs into pulse outputs and provides configurable 5 V outputs.
The module M83200 contains:
- 4 independent AC signal converters
- To adapt low amplitude AC (e.g. sinusoidal) signals of various sensors to the counter inputs of Meteo-40 plus data loggers. The sinusoidal signal is converted in a rectangular pulse signal with the same frequency.
- 2 individually configurable ports with the following configuration options:
- Current limit to 10mA (470Ω)
- Pull-up resistor 5.1 kΩ with current limit 1 mA
- Stabilised and ripple-free 5V output with active current limit 110mA
Specifications
| Electrical characteristics (Default settings) | ||||
|---|---|---|---|---|
| Parameter | Pin / Ports | Min | Typical | Max |
| Supply voltage (DC) Quiescent current |
13 | 9V 11mA |
32V 16mA |
|
| Ground GND | 15 | |||
| Configurable Outputs | ||||
| Output (5V DC) (ϑ = 25°C) | 14, 16 | 5.2V 110mA |
5.8V 130mA |
|
| Pull-up current limit 1mA (Low current configuration 5.1kΩ) |
14, 16 | 0.97mA | 1.05mA | |
| Pull-up current limit 10mA (High current configuration) |
14, 16 | 10.5mA | 11.4mA | |
| AC Voltage Converters | ||||
| Input sensitivity of converter | 2, 3, 6, 7 | 115mV | 120mV | |
| Ground GND | 4, 8 | |||
| Output level low | 9, 10, 11, 12 | 0V | 0.01V | |
| Output level high | 9, 10, 11, 12 | 5V | 5.8V | |
| Operating temperature | -40°C | +75°C | ||
| Fuse T0.8A (time lag, slow-blow): 5 x 20mm | ||||
Housing dimension (width x height x depth): 22.5 x 110 x 115mm
Mounting on DIN-rail (35 x 7.5mm)
Terminal: wire cross section from 0.25 to 1.5mm²
Terminal Earth: recommended wire cross section 1.5mm²
(Keep wire length as short as possible)
